MasterPhono Phonostage By MoFi Electronics (Demo)

Purchase Date: March 2024
Condition: As-new, with no marks, scuffs, or visible signs of wear.
Usage: Used for 3 months in the Jaguar reference system, until we received our Phasemation phono preamp.
Shipping/Insurance: Included
Warranty: Full Manufacturer’s Warranty

Elevating vinyl playback with precision engineering

Crafted through a collaboration with acclaimed audio engineer Peter Madnick—whose work has shaped some of the finest components in high-end audio—the MasterPhono is a premium, all-analog phono preamplifier designed for true vinyl enthusiasts. Engineered with the goal of capturing the sonic character of legendary MFSL vinyl reissues, this unit delivers exceptional clarity, depth, and detail. Whether you’re rediscovering your record collection or fine-tuning a reference-level system, the MasterPhono offers a listening experience that honors the original recording with stunning fidelity.

Versatile inputs, infinite soundscapes

What sets the MasterPhono apart is its incredible versatility. Featuring both balanced and single-ended outputs along with dedicated inputs, it’s built to integrate seamlessly into a wide range of high-performance audio systems. User-configurable settings are easily accessible through its intuitive front panel controls, making setup and fine-tuning a breeze. The classic analog meters proudly reflect the unit’s deep analog roots, while a built-in USB port ensures compatibility with future software updates—blending timeless design with modern flexibility.

Precise input flexibility

The MasterPhono offers two distinct input modes to suit a wide range of phono cartridges. Choose the standard “Voltage Input” via RCA or XLR for traditional setups, or opt for the innovative “Current Input” mode—designed specifically for low source-impedance cartridges. This advanced option employs Trans-impedance Dynamic Loading technology, unlocking greater detail and musicality from select cartridge types for an optimized, high-fidelity listening experience.

Perfect loading

The ideal match for your phono cartridge with ten selectable impedance loading settings, ensuring optimal performance and sonic accuracy. For added flexibility, a rear-panel RCA input labeled “Custom” allows for user-defined loading—giving audiophiles full control to fine-tune their setup to perfection.

Dual function vu meters

Dual meters can be used for monitoring or calibration of cartridge azimuth.

Features

• RCA/XLR: Voltage & Current inputs, Trans-impedance dynamic loading
• Dual-chassis: Power/Signal isolation, low noise, separate grounding
• Gain settings: 40/50/60/70dB, Impedance: 10 settings + Custom
• Fully discrete balanced circuitry, servo-controlled, DC-coupled, high pass filter
• Passive RIAA: Precise parts, NOS capacitors, accurate resistors
• Cascaded voltage regulation, ultra-low noise
• Remote controlled: Input, gain, mute, mono, meter, subsonic filter
• Dual Function VU meters for monitoring or cartridge calibration

Gain:
Selectable gain for MM or MC 40db, 50db, 60db, 70db

THD:
10mV@1KHZ MM low: 0.005% A-Weighted
10mV@1KHZ MM high: 0.005% A-Weighted
1mV@1KHZ MC low: 0.010% A-Weighted
1mV@1KHZ MC high: 0.013% A-Weighted

Loading:
15 Ohms, 30 Ohms, 50 Ohms, 75 Ohms, 100 Ohms, 500 Ohms, 1K Ohms, 10K Ohms, 47K Ohms+150pF, & “Custom”

Max Output:
@1% THD, 10 Volts RMS

RIAA Accuracy:
-+/- 0.05db

Frequency Response:
10Hz–50KHz ±0.20dB

Weight:
15 lb / 6.8 kg

Warranty:
Five years parts & labor
