RD-101 Mk.II DAC By Vitus Audio

Dedicated to digital

As digital audio becomes the primary source for many enthusiasts, the RD-101 Mk.II DAC stands out as a perfect companion to high-end amplifiers. Built with technology inspired by award-winning designs, it delivers exceptional performance in a compact chassis without compromising quality.

At its core is the powerful Sabre ES9028PRO 32-bit HyperStream II DAC chip, offering an impressive 140dB dynamic range and -122dB THD+N for stunning audio clarity, unparalleled dynamics, and ultra-low distortion.

An advanced ultra-low-noise power supply regulator maximizes the DAC’s potential, making the RD-101 Mk.II a standout performer in its class and an excellent choice for audiophiles seeking unmatched value.

Huge connectivity

The RD-101 DAC is designed to seamlessly accommodate all your digital audio needs. With five digital inputs and a dedicated RJ45 streamer input, it ensures compatibility with a wide range of digital sources.

Its USB audio input supports NativeDSD up to 128 and PCM resolutions up to 384kHz/32-bit, delivering exceptional sound quality. Additionally, the built-in streaming module supports popular network audio protocols, including DLNA/UPnP, Tidal Connect, and Spotify Connect, offering versatile and effortless streaming options.

Finishing

The RD-101 Mk.II is available in three elegant standard finishes: Pure White, Jet Black, and Warm Silver. For a more personalized touch, popular custom finishes like Titanium Orange, Dark Champagne, and Titanium Grey are also offered.

Output XLR analogue

• Available: 1 (L+R)
• Impedance: 75Ω
• Frequency response: +800kHz
• Signal to noise ratio: >110dB @ 1kHz
• THD + noise: <0.01%

Output RCA analogue

• Available: 1 (L+R)
• Impedance: 75Ω
• Frequency response: +800kHz
• Signal to noise ratio: >110dB @ 1kHz
• THD + noise: <0.01%

DAC

• Master clock: 24.576 MHz +/- 5ppm
• DAC: ES9028PRO

DIGITAL AUDIO INPUT USB

• Available: 1x USB B
• Sample rate: 384 kHz + DSD128
• Resolution: 24bit

DIGITAL AUDIO INPUT AES/EBU

• Available: 2x XLR
• Impedance: 110Ω
• Sample rate: 192kHz
• Resolution: 24bit

DIGITAL AUDIO INPUT S/PDIF

• Available: 2x RCA
• Impedance: 75Ω
• Sample rate: 192kHz
• Resolution: 24bit

DIGITAL AUDIO INPUT Streamer

• Available: 1x RJ45
• Sample rate: 192kHz + DSD 64
• Resolution: 24bit

POWER CONSUMPTION

• Standby: <1W
• Operation: 25W

Dimensions

• Height: 103mm including feet
• Width: 435mm
• Depth: 396mm / 431mm with binding post
• Weight: 12kg
• Material: Aluminium for body parts
