MP-D201 Mk.III DAC By Vitus Audio

The T+A MP 2500 R Multi Source Player represents one of the most advanced digital playback solutions in the R-Series lineup. Designed for uncompromising high-resolution audio performance, it combines a premium multi-source player with a sophisticated PCM / DSD DAC. While it shares the core design philosophy of the MP 2000 R MK II, the MP 2500 R expands its capabilities with enhanced engineering and a high-end SACD drive derived from T+A’s flagship MP 3100 HV player.

For PCM audio playback, the player utilizes T+A’s renowned double-differential quadruple converter architecture, supported by advanced digital signal processing for exceptional clarity and precision. DSD signals are handled through T+A’s proprietary True 1-Bit DSD converter, originally developed for the PDP 3000 HV. This approach processes DSD in its native bitstream format rather than converting it, allowing the MP 2500 R to reproduce DSD formats up to DSD512 via USB with outstanding accuracy and detail.

The MP 2500 R also features a powerful high-resolution streaming platform, enabling access to network audio sources, Internet radio, and popular music services. With support for LAN, WLAN, USB Master Mode, and HD streaming from network servers, it integrates easily into modern home audio systems. A built-in digital tuner supports FM, FM-HD, and DAB+, while a high-quality Bluetooth module allows convenient wireless music playback from mobile devices.

Control is simple and flexible. The player can be operated using the SRC 1 infrared remote or the T+A MusicNavigator App, available for iOS and Android. The app provides comprehensive control of all compatible components and displays detailed information such as streaming data, station names, and radio text directly on your device.

SACD Drive

For listeners who value physical media, the MP 2500 R includes a newly developed SACD transport designed to deliver outstanding playback quality for both CD and SACD discs. The drive incorporates modern decoder technology for fast access times and precise error correction, ensuring accurate playback of PCM (CD) and DSD (SACD) formats.

Special attention has been given to the mechanical construction of the transport to minimize vibration and interference. The disc mechanism is mechanically isolated from the rest of the player, while a solid aluminum structure and heavy damping plate help prevent external vibrations from affecting playback. The precision disc drawer operates on machined stainless-steel guide rods, and the disc sits in a specially coated ABS cradle designed for smooth, stable operation.

Together, these elements make the T+A MP 2500 R a versatile high-performance source component capable of delivering exceptional sound from both digital files and physical media.

Sound Stage
“The T+A gear never lost its composure on anything I played through it. Whether at concert volume or quiet evening listening levels the character and presentation remained absolutely consistent, stable and musically expressive.”

https://www.soundstageaustralia.com/index.php/reviews/631-t-a-elektroakustik-mp-2500-r-multi-source-sacd-player-and-pa-2500-r-integrated-amplifier

Hifi News
“There are a few things still to sort at the time of writing, including Roon integration and the Music Navigator app, but there’s no doubt this ‘bridge’ player still delivers everything in its considerable arsenal without compromise. Its big, bold but lavishly detailed sound matches the solid, precision engineering of its design and construction. It’s undeniably expensive, but the performance is sublime.”

https://www.hifinews.com/content/ta-mp-2500-r-digital-media-player

Digital Connecting Board

• S/P-DIF digital inputs : 1x Coax, 2x BNC, 2x TOS-Link
• USB (Device Mode) : 1x USB Device Mode asynchronous
• USB (Master Mode) : 2 x USB Master-Mode for USB-storage devices

FM – Tuner

• Reception standard : FM, FM-HD
• Frequency range : 87,5 – 108 MHz;
• Sensitivity :(>65 dBA S/N) 1 ?V
• Overload margin : 103 dB uV
• Total harmonic distortion : 0,1%
• Signal / noise ratio (mono / stereo): 72/62 dB
• Stereo channel separation : 50 dB
• De-emphasis : 50/75 us
• Data services : RDS/RDBS, station name (PS), programme type (PTY), radiotext (RT)

DAB – Tuner

• Reception standard : DAB, DAB+
• Frequency range : 168 -240 MHz (Band III)
• Sensitivity (BER = 10 – 4) : 2,0 ?V
• Overload margin : 103 dB uV

Bluetooth

• Bluetooth : A2DP (Audio), AVRCP 1.4 (Control) / aptX®, MP3, SBC

Connections

• Analog outputs high level (RCA) : 2,5 Veff / 50 Ohms
• Analog outputs balanced (XLR) : 5,0 Veff / 50 Ohms
• Digital outputs : 1 x coax, IEC 60958 S/P-DIF (LPCM)

D/A-Converter

• PCM : Double differential quadruple converter with four D/A converters per channel, 32-bit sigma-delta, 352.8kSps/384kSps
• DSD : T+A-True-1Bit DSD D/A-converter up to DSD 512 (22 MHz)
• Frequency response PCM 44,1 kSps : 2 Hz – 20 kHz
• Frequency response PCM 48 kSps / DSD 64 : 2 Hz – 22 kHz / 2 Hz – 44 kHz
• Frequency response PCM 96 kSps / DSD 128 : 2 Hz – 40 kHz / 2 Hz – 60 kHz
• Frequency response PCM 192 kSps / DSD 256 : 2 Hz – 80 kHz / 2 Hz – 80 kHz
• Frequency response PCM 384 kSps / DSD 512 : 2 Hz – 100 kHz / 2 Hz – 100 kHz
• Analog filter : Phase-linear Bessel filter of 3rd Order with 100 kHz cut-off frequency
• Total harmonic distortion : < 0,001 %
• Signal / noise ratio : 116 dB
• Channel separation : 110 dB

Mains / Accessories / Dimensions

• Control interface : R2-Link
• Remote control : SRC 1, T+A MusicNavigator APP
• Mains connection : 100-240 V, 50-60 Hz
• Power consumption max. : 40 Watts
• ECO-Standby : 0,3 Watt
• Auto power off function : yes (after 90 minutes without audio signal)
• Optional Accessories : Power Three HD (Carbon) | Power Bar | Audio Quad (Carbon) | Audio Triax (Carbon) | IP-Steuerung
• Dimensions (H x W x D) : 16,5 × 46 × 40 cm
• Weight : 11,3 kg
• Finishes : Silver anodized aluminum (43), black anodized aluminum (42), brushed

Technical modifications reserved
